Number of Turns-Counting.
10
Max. Indication
999
Matching Shaft Dia. (mm)
Standard 6, Special 3, 3.175, 4, 6.35
Combinable Helicalohm Pot.
(Matching shaft length of 25mm) 20HP, 46HD, 22HP, 20HHP, 22HHP, 25HP
Standard Color of Case
Ivory
Flexible coupling
Yes
Lock Device
Yes
Operating Temperature Range
-30℃~+85℃
Mass
Approx.60g
Number of Turns-Counting.
10
Max. Indication
999
Matching Shaft Dia. (mm)
Standard 6, Special 3, 3.175, 4, 6.35
Combinable Helicalohm Pot.
(Matching shaft length of 25mm) 20HP, 46HD, 22HP, 20HHP, 22HHP, 25HP
Standard Color of Case
Silver
Flexible coupling
Yes
Lock Device
Yes
Operating Temperature Range
-30℃~+85℃
Mass
Approx.60g
Number of Turns-Counting.
10
Max. Indication
999
Matching Shaft Dia. (mm)
Standard 6, Special 3, 3.175, 4, 6.35
Combinable Helicalohm Pot.
(Matching shaft length of 25mm) 20HP, 46HD, 22HP, 20HHP, 22HHP, 25HP
Standard Color of Case
Silver
Flexible coupling
No
Lock Device
Yes
Operating Temperature Range
-30℃~+85℃
Mass
Approx.60g
Number of Turns-Counting.
100
Max. Indication
999
Matching Shaft Dia. (mm)
Standard 6, Special 3, 3.175, 4, 6.35
Combinable Helicalohm Pot.
(Matching shaft length of 25mm) 20HP, 46HD, 22HP, 20HHP, 22HHP, 25HP
Standard Color of Case
Ivory
Flexible coupling
Yes
Lock Device
Yes
Operating Temperature Range
-30℃~+85℃
Mass
Approx.60g
Special color
Special colors on housing and spin plate on the top of the knob (Black, etc.)
Specially face plate
Special graduation such as with a decimal point, comma, etc
