Draw-wire position sensor
Economy version
Measuring rang：100~1500mm
Output signal：Modbus RTU、CANopen
Measure range
Max. 1500mm
Protection degree
IP54（electrical parts）
Force
2N~5.5N
Mechanical Life expectancy
2,000,000
Mass
Approx.350g
Housing material
Anodized aluminium alloy
Draw wire
0.6mm coated polyamid stainless steel
Max. reciprocating speed
300mm/s
The length of the cable
1.5m
Operating temperature range
-30℃～+85℃
Storage temperature range
-30℃～+85℃
Shock
10G, 10Hz~1.5kHz
Vibration
50G, 10ms
Applied voltage
5V±10%、12~30V
Output port
RS485、CAN
Output signal
Modbus RTU、CANopen
Linearity tolerance
0.3%FS
Repeatability accuracy
0.03%
Single-turn resulation
0.2mm (Standard)、0.025mm (Optional)
Special specifications
Available for multi-segment output, special cables, high protection degree, etc.
