Model No.

CFL200；CFL300

Mechanical stroke (MS)

Approx. 203mm；Approx. 303mm

Life expectancy, shaft reciprocating motions

No load at 120 c.p.m., 10,000,000 reciprocating motions (except stroke 500mm or longer), Total resistance value variation: ≤±10％ against initial value, Independent linearity tolerance: ≤150％ of specified value, Output smoothness: ≤150％ of specified value.

Friction

≤0.2N (20gf)

Mass

Approx.70g；Approx.100g

Resistance temperature coefficient

±400p.p.m./℃

Operating temperature range

-30℃~+105℃

Temperature cycle

5 cycles under -30℃～+105℃, total resistance value variation: ≤± 10％, No mechanical damage.

Exposure at low temperature

24 hours at -30℃, Total resistance value variation: ≤±5％, No mechanical damage.

Exposure at high temperature

1,000 hours at 105℃, Total resistance value variation: ≤±10％, No mechanical damage.

Vibration

10Hz～2000Hz, 147m/s², 12 hours, Total resistance value variation: ≤±5％, No mechanical and electrical damage.

Shock

490m/s², 11ms, 18 times, Total resistance value variation: ≤±1％, No mechanical and electrical damage.

Moisture resistance

40℃, 95％RH, 120 hours, Total resistance value variation: ≤±10％, Insulation resistance: ≥10MΩ.

Model No.

CFL200；CFL300

Electrical stroke

200±1mm；300±1mm

Standard resistance values

2k,5k,10k (Ω)；5k,10k,20k (Ω)

Total resistance tolerance

±20％ (M)

Independent linearity tolerance

±10％ (K)

Output smoothness

±0.5％ ±0.1％

Contact resistance variation

±0.05％；±0.05％

Power rating

≤against input voltage 0.1%

Insulation resistance

≤2% C.R.V.

Dielectric strength

2.0W；2.5W

Special mechanical specifications

Mechanical stops at both ends
