Model No.

LSM22-10-5；LSM22-20-5；LSM22-30-5

Mechanical stroke

Approx.14mm；Approx.24mm；Approx.34mm

Mass

Approx.30g；Approx.40g；Approx.60g

Protection grade (IP)

IP40

Friction

≤0.1N (10gf)

Life expectancy (Shaft reciprocating motions)

Approx.50,000,000

Temperature coefficient

≤±2.5%Vout·FS

Operating temperature range

-40℃～+105℃

Storage temperature range

-40℃～+105℃

Thermal shock

-50℃~+105℃, 5 cycles

Exposure at low temperature

-50℃, 24hours

Exposure at high temperature

+105℃, 1,000hours

Moisture Resistance

40℃, 95％RH,120hours

Vibration

10~2,000Hz 196m/s2, 12hours

Shock

980m/s2 (18 times)

Model No.

LSM22-10-5；LSM22-20-5；LSM22-30-5

Effective electrical stroke

Approx.10mm；Approx.20mm；Approx.30mm

Applied voltage

5V.D.C.

Output voltage range

Approx. 10％~90％ Vin

Current consumption

Approx.5mA

Load resistance

10kΩ min.

Independent linearity tolerance

±0.5%FS

Drift at center position

≤±0.5%Vout·FS

Spring return device incorporated

Spring return device incorporated
