Low-cost
1-dimensional coordinate type joystick
With conductive plastic element
Multifunctional industrial joystick
Controlling range of operating lever
±20°～± 25° from center position.
Operating force
Standard spring return device : Automatically return to center. Standard Approx. 1N～2.5N (Approx. 100gf～250gf), With rubber cover Approx. 1N～5.5N (Approx. 100gf～550gf)
Operating temperature range
-20℃~+60℃
Vibration
10~55HZ，98m/s2
Shock
294m/S2
Life expectancy
Approx.2,000,000 operations
Mass
Approx.100g
Potentiometer mounted
Special conductive plastic resistive element is exclusively used for 30JL series
Total resistance value
10KΩ±20%
Independent linearity tolerance
±5%
Electrical rotating angle
Approx. 40°
Rated power 0.1W
0.1W
Output smoothness
＜against input voltage 0.2%
Contact resistance variation
＜6%C.R.V.
Resolution
Essentially infinite
Dielectric strength
1 minute at 500V.A.C.
Insulation resistance
＞100MΩ（250V.D.C）
