Operating angle

Approx. 20°

Operating force

10～60N

Mechanical life expectancy

10,000,000

Operating temperature

-40℃~+85℃

Storage temperature

-40℃~+85℃

Vibration

10~55Hz 98m/s²

Shock

294m/s²

Mass

Approx. 1100g

Protection degree

IP65

Standard resistance

10KΩ±15%, 5KΩ±15%

Independent linearity tolerance

±3%

Resolution ratio

Essentially infinite

Power rating

0.25W

Output smoothness

<Against input voltage 0.2%

Contact resistance variation

<5%CRV

Electrical life expentancy

10,000,000

Insulation resistance

>1000MΩ (500V.D.C.)

Dielectric strength

1min (500V.A.C.)

Rating

125V.A.C./5A

Electrical life expectancy

200,000

Insulation resistance

>100MΩ (500V.D.C.)

Dielectric strength

1min (1000V.A.C.)

Mechanical specifications

Kick-down device

Electrical specifications

POT. with other resistance(1K, 2K), special output characteristic, speical cable length, etc.

With connecters

DTM04-6P、AMP 174359-2
